What is a Ford S-Max Mk1 airbag control unit?
The Ford S-Max Mk1 airbag control unit is the central safety unit in the vehicle, deploying all occupant restraint systems, such as airbags and seatbelt pretensioners, in the event of an accident. It continuously monitors sensors in the vehicle, stores important crash data, and ensures the correct functioning of the entire airbag system for occupant safety.
As a key component of passive safety, the control unit receives signals from impact sensors and decides on the necessary triggering measures in milliseconds. It is programmed specifically for the vehicle and contains important data about the vehicle's configuration.
The airbag control unit not only manages deployment but also records any errors and crash events that occur, which are indicated by the airbag warning light. Repair or replacement is essential if the system fails.
Why is the Ford S-Max Mk1 airbag control unit faulty?
A Ford S-Max Mk1 airbag control unit often fails because it stores crash data after an accident, preventing reuse without a professional reset, or due to internal electronic errors. Age-related wear and tear or short circuits can also lead to failures that impair airbag function and activate the warning light.
Common causes include internal software or hardware errors that require a module reset or repair. Such errors prevent communication with diagnostic devices or the proper functioning of the safety system.
After deployment during an accident, irreversible crash data is stored in the control unit, requiring replacement or professional resetting of the module. The airbag warning light remains permanently active in this state, even if the mechanical components have been replaced.
Common error codes for Ford S-Max Mk1 airbag control unit repair
During Ford S-Max Mk1 airbag control unit repairs, specific error codes may occur that indicate internal problems with the control unit or communication failures. These DTCs are crucial for accurately diagnosing and locating the defect before performing a repair or reset.
- B1000 → Control unit communication error → Error in the internal communication of the airbag control unit or to the vehicle bus.
- B1660 → Internal error in the airbag control unit → Software or hardware error within the airbag module itself.
- B1697 → No communication with the airbag control unit → Defect in the control unit or interruption in the communication line.
- B1700 → Crash data present in memory → Crash data stored after an accident that requires a reset.
Reading these codes with a diagnostic tool such as the Ford IDS or Bosch ESI[tronic] is the first step in troubleshooting. Code B1700, in particular, indicates the need to erase crash data.
The error codes mentioned relate exclusively to the control unit and not to sensors, belt pretensioners or other external airbag components of the Ford S-Max Mk1 airbag system.
What part numbers are available for the Ford S-Max Mk1 airbag control unit repair?
For Ford S-Max Mk1 airbag control unit repairs, specific and 100% verified OEM part numbers are crucial to ensure compatibility and safety. These numbers, often provided by Ford itself or by supplier Bosch, identify the exact airbag control unit for your vehicle model.
It is essential to use only the correct and original part numbers when replacing or repairing. The main suppliers for these airbag control units for the Ford S-Max Mk1 are Ford and Bosch.
- 6M2T-14B056-AE (Bosch 0 285 010 223)
- AM2T-14B321-AC (Bosch 0 285 010 835)
- BM2T-14B321-AB (Bosch 0 285 010 673)
- BM2T-14B321-AC (Bosch 0 285 010 323, 0 285 010 950)
- BM5T-14B321-CE (Bosch 0 285 010 930)
These numbers guarantee that you will receive a genuine airbag control unit that is exactly compatible with the Ford S-Max Mk1 model years 2006-2015 and not any sensors or other modules.
Where can I find a Ford S-Max Mk1 airbag control unit for repair?
You can find a Ford S-Max Mk1 airbag control unit for repair at specialized workshops that specialize in airbag module service and repair. These workshops offer professional diagnostics, crash data erasure, and repair of internal control unit errors to restore the system's full functionality.
You can search online for "Ford S-Max Mk1 airbag control unit repair" to find specialized service providers. Many of these companies offer a mail-order service where you can send in your defective control unit.
It's advisable to choose a service provider that explicitly handles the listed OEM part numbers for the Ford S-Max Mk1 and offers transparent pricing. Professional repairs often save money compared to purchasing a new module and restore the functionality of the original module.
