What is a Toyota Corolla E160 airbag control unit?
The Toyota Corolla E160 airbag control unit is your vehicle's central safety unit, responsible for activating all occupant restraint systems in the event of a collision. It continuously monitors sensor data, stores important crash information, and ensures the proper function of airbags and seatbelt pretensioners.
This electronic unit processes signals from various sensors in the vehicle. In the event of an accident, it makes precise decisions about whether to activate the safety systems to ensure maximum occupant safety.
Once activated, the control unit stores the relevant crash data. This data must be deleted before the system can be used again or repaired.
Why is the Toyota Corolla E160 airbag control unit defective?
A Toyota Corolla E160 airbag control unit can be defective due to internal electronic errors, crash data being stored after an accident, or short circuits in the airbag circuits. Such defects often cause the airbag warning light to illuminate and require professional repair.
The most common cause of a defect is the storage of crash data after an accident, which requires reprogramming. Age-related wear and tear or electrical malfunctions in the vehicle's electrical system can also lead to failures.
Faults such as internal short circuits or interruptions in the airbag or seatbelt pretensioner firing circuits are detected by the control unit. This impairs the functionality of the entire safety system and requires immediate diagnosis.
Common error codes for Toyota Corolla E160 airbag control unit repair
During a Toyota Corolla E160 airbag control unit repair, specific error codes indicate problems directly related to the control unit or its monitored circuits. These B-codes are essential for diagnostics to identify the exact failure and resolve it.
Reading the fault codes using a suitable OBD-II airbag scanner is the first step. These codes help determine whether there is a short circuit, an open circuit, or an internal communication error.
- B1000 → Control unit communication error → Internal problem in the airbag ECU or connection error.
- B1920 → Short circuit in the rear left airbag circuit → Electrical defect in the wiring or the airbag module.
- B1921 → Open circuit in the rear left airbag circuit → Broken connection to the airbag module or defective airbag.
- B1922 → Short circuit to ground in the rear right airbag circuit → Ground contact in the wiring or on the airbag module.
- B1923 → Short circuit to battery (12V) in the rear right airbag circuit → Power contact to 12V supply in the wiring or on the airbag module.
- B1925 → Short circuit in the rear right airbag circuit → General electrical fault in the airbag circuit.
- B1926 → Open circuit in the rear right airbag circuit → Open circuit or defective airbag module.
- B1927 → Short circuit to ground in the rear right airbag circuit → Faulty ground contact in the airbag circuit.
- B1928 → Short circuit to battery in the rear right airbag circuit → Unwanted contact with the battery supply.
- B1941 → Airbag Crash Sensor #1 Feed/Return Circuit Open → Problem in the signal or supply circuit of the crash sensor.
What part numbers are available for the Toyota Corolla E160 airbag control unit repair?
For Toyota Corolla E160 airbag control unit repairs, specific, verified OEM part numbers are crucial to ensure correct compatibility and functionality. Using the correct part number is essential for a successful safety system repair.
Verified OEM part numbers for the Toyota Corolla E160 airbag control unit include 8917002G60, 8917012160, and 8917042D50. These numbers are sourced from professional parts sources and are listed specifically for the E160 model.
When replacing or repairing your airbag control unit, it is essential to accurately match the part number. This is the only way to ensure that the replacement part is fully compatible with the vehicle's equipment and safety features.
